CF-20
De Toughbook 20 biedt als fully-rugged demonteerbare notebook een ongekend niveau van veelzijdigheid voor mobiele zakelijke computers. Deze biedt het beste van het beste voor mobiele werknemers en kan op zes verschillende manieren ingezet worden om tegemoet te komen aan elke zakelijke noodzaak. Dankzij het touchscreen dat met handschoenen bediend kan worden, een "hot swappable" accu met een levensduur tot wel 17 uur en een speciaal gebouwde Vehicle Mount en Desktop Port Replicator, is de Panasonic Toughbook 20 een ongeëvenaard zakelijk apparaat. Product eco-design information in accordance with EU Regulation 617/2013: https://www.ptc.panasonic.eu/compliance-documents
Specificaties:
- Intel® Core™ i5-7Y57 vPro™
- 8GB (max. 16GB)
| Mobile Computing Platform | Intel® Core™ i5-7Y57 vPro™ processor |
|---|---|
| Operating System | Windows 10 Pro |
| RAM | 8GB (max. 16GB) |
| Graphic Chip | Intel® HD Graphics 615 |
| Storage | 256GB SSD (512GB optional) |
| LCD | 10.1" Active Matrix (TFT) colour LCD 1920 x 1280 (WUXGA) LCD with sunlight-viewable glove-enabled capacitive touchscreen (up to 800cd/m²), IP55 Digitiser optional |
| Bluetooth™ | 4.2 + EDR Class 1 |
| Wireless LAN | Intel® Dual Band Wireless-AC 8265 |
| Mobile Broadband* | 4G LTE, supports 3G |
| GPS* | U-Blox NEO-M8N |
| LAN | x1 (Tablet) x1 (Keyboard) |
| Sound | WAVE and MIDI playback, Intel® High Definition Audio subsystem support |
| Security | TPM (TCG V2.0 compliant) Password security (supervisor password, user password, hard disc lock) Integrated hardware security lock slot |
| Front Camera | 2mpixel (with IR for Windows Hello) |
| Rear Camera | 8mpixel with autofocus and LED flash |
| SD/SDXC Memory Card | x1 Micro (Tablet) x1 (Keyboard) |
| Configuration port (Tablet)** | Serial, 2D Barcode Reader, 2nd USB 2.0 |
| USB 3.0 | x3 (x1 Tablet, x2 Keyboard) |
| USB 2.0 | x1 (Keyboard) |
| HDMI | x1 (Tablet) x1 (Keyboard) |
| VGA | x1 (Keyboard) |
| Native Serial Port | x1 optional (Tablet) x1 (Keyboard) |
| Headset | x1 (Tablet) x1 (Keyboard) |
| DC In | x2 (Tablet + Keyboard) |
| Port Replicator | x1 (Keyboard) |
| Dual Antenna Connector | x1 (Keyboard) |
| Business Expansion Module (Tablet)** | Smart Card Reader, NFC, Fingerprint Reader |
| AC Adapter | Input: 100V - 240V AC, 50Hz/60Hz, Output: 16 VDC, 4.06A |
| Battery | x2 Li-Ion (3 cell, 29Whr) |
| Battery Life | Tablet + Keyboard: Approx. 17 hours (Mobile Mark™ 2014) Tablet: Approx. 8.5 hours (Mobile Mark™ 2014) |
| Power Management | Hot swap, Standby function, ACPI BIOS |
| Dimensions (WxHxD) | 272 mm × 233 mm × 33.5 mm / 10.71" × 9.17" × 1.32" |
| Weight | Approx. 1.89kg / 4.17lb |
| Drop Resistance | MIL-STD 810G, 120cm*** |
| Dust Resistance | IEC529 (JIS C0920) IP6x*** |
| Water Resistance | IEC529 (JIS C0920) IPx5*** |
| Operating Temperature | MIL-STD 810G, -29 °C to 60 °C *** |
| Standard Configuration | Touchscreen Model: CF-20mk2, 8GB RAM, 256GB SSD, 2x battery pack, stylus pen Dual-Touch Model: CF-20mk2, 8GB RAM, 256GB SSD, 2x battery pack, IP55 digitiser pen |
| Included in the box | Power Supply, Power Cord, Display cleaning cloth and User Manual |
| Footnote | *Optional **One option exlusive possible in configuration port / business expansion module ***Tested by an independent third party lab following MIL-STD-810G and IEC 60529, Sections 13.4, 13.6.2, 14.2.5 and 14.3 |
| * | |
| ** | |
| *** |
Deze toughbook is beschikbaar in meerdere versies:
